Outline Technical Specification
Drive bays
• Supplied with bays for two up to 2TB drives
configured as a RAID 1 system
Controls
• Rear panel power switch
• Front panel back-lit on/off button
Indicators
• Power button LED illuminates blue during
startup and shudown; white when operating.
• Six front-panel LEDs as follows (L-R):
LED 1: Error indicator
On=boot failure; flashing=drive mount failure.
LED 2: Temperature indicator
On=product overheating
LED 3: CPU load indicator
On=CPU is running at greater than 80%
usage.
LED 4: RAID drive 1 failure indicator
On=RAID marked drive 1 as failed.
LED 5: RAID drive 2 failure indicator
On=RAID marked drive 2 as failed.
LED 6: Ethernet disconnect indicator
On=Ethernet cable is not detected
• If RAID1 and RAID2 LEDs are toggling, one
of the drives is being restored to – ie a single
new drive has been inserted with an existing
working drive.
• If all six LEDs are illuminating sequentially
back and forth, the drives are being initialized
with a new filesystem, i.e. two new drives
have been inserted.
Power
• Mains operation, universal voltage power
