Spectral DMA-180 Stereo Power Amplifier
Power Output:
(continuous)
@ 8 ohms - 200 Watts RMS
@ 4 ohms - 400 Watts RMS
@ 2 ohms - 683 Watts RMS
Output Current:
60 Amps peak per channel
Frequency Response:
±0.1 dB, DC-150 KHz
±1 dB, DC-1 MHz
±3 dB, DC-1.8 MHz
Distortion:
Static:
Less than 0.015% from DC to 100 KHz Typically 0.009% @ 200 WRMS/8 ohms
Dynamic:
8 Tone Cluster Test 20 KHz @ 500 Hz separation; 0.01% 8 ohms; 0.015% 4 ohms
Speed:
Rise Time:
Less than 400 nanoseconds
Settling:
1.5 microseconds to -40dB
Slew Rate:
600 volts/microsecond
Noise:
Signal to Noise:
97dB unweighted, 107dB ASA A
Crosstalk:
98dB @ full power 8 ohms
Input:
Impedence:
100K ohms in parallel with 100 pf
Sensitivity:
1.5 volts/nominal output
Power Supply:
Line Voltage:
100 volts, 120 volts, 240 volts (internal wiring)
AC Voltage Range:
±10%
Maximum Consumption:
1600 Watts
Quiescent Consumption:
250 Watts
Operating Temp:
0° to 50° Celsius range; 32° to 122° Farenheit
Protection Features:
DC Protection Servo:
0.5 volt range
Current Limit Onset:
40 Amps
Thermal Protect Threshold:
85° Celsius, 185° Farenheit
AC Main Fuses:
2 @ 4A 3AG slo-blo, for 100 - 120 VAC,
2 @ 2A 3AG slo-blo, for 220 - 240 VAC
Fuse Status:
LED indicator (2)
Size and Weight:
Dimensions:
48cm (19")W x 17cm (6 1/4")H x 48cm (19")D
Weight:
60 lbs, 27.2 KG Net
