Product Description
Details
specs
General
Functionality
Internet radio playback, digital audio playback, digital photo playback
Manufacturer
Pioneer
Display
Display Dimmer
Yes
Audio
Response Bandwidth
5 - 100000 Hz
Signal-To-Noise Ratio
103 dB
Networking
Connectivity
IEEE 802.3 (Ethernet), IEEE 802.3u (Fast Ethernet)
Network Protocols Supported
DHCP
Digital Media & Network Players
Digital player type
digital player
Type
network audio player
Supported Digital Audio Standards
AAC, FLAC, MP3, PCM, WAV, WMA
Digital Player Features
JPEG photo playback, USB flash drive playback
Audio System
Type
AV network receiver
Subcategory
AV components
Functions
AV receiver, digital player, network audio player
Media Content Source
Network, USB-host
Audio Formats
AAC, FLAC, MP3, PCM, WAV, WMA
Sound Output Mode
Surround Sound
Audio D/A Converter
24bit / 192kHz
Built-in Decoders
DTS 96/24, DTS Neo:6, DTS decoder, DTS-ES decoder, DTS-HD High Resolution, DTS-HD Master Audio, DTS-HD decoder, Dolby Digital, Dolby Digital Plus, Dolby Digital Surround EX, Dolby Pro Logic IIx, Dolby TrueHD, THX Select 2
Surround Sound Effects
Neural Surround
Surround System Class
7.1 channel
THX certified
Yes
Digital Sound Processor (DSP)
Yes
Additional Features
Bi-Amplifying, Multi-Channel Acoustic Calibration Circuit (MCACC), Sirius satellite radio ready, THX Select2 certified, XM satellite radio ready, three-zone capability
Built-in Clock
sleep timer
Power Device
Nominal Voltage
AC 120 V
Frequency Required
60 Hz
Power Consumption Operational
330 Watt
Type
power supply
Header
Brand
Pioneer
Product Line
Pioneer Elite
Model
SC-05
Packaged Quantity
1
Built-in Display
Type
fluorescent
Miscellaneous
Included Accessories
AM antenna, FM antenna, auto calibration microphone, universal remote control
Timer
sleep
Equalizer
Equalizer
Yes
Equalizer Band Qty
9 bands
Amplifier
Input Impedance
47 Ohm
Input Sensitivity
335 mV
Amplifier Output Details
Output Power / Channel
130 Watt
Output Impedance / Channel
8 Ohm
Frequency Response
20 - 20000 Hz
Total Harmonic Distortion (THD)
0.09 %
Channel Type
surround
Channel Qty
7
Radio
Tuner Type
digital
Tuner Bands
AM/FM
Additional Features
XM HD Surround Sound
Inputs & Outputs
HD connectors
HDMI connection(s) on this receiver make it a great choice for your High-Def home theater. One cable carries digital audio and video data directly to your display.
Headphone Jack
Yes
Optical Digital Input
Yes
Remote Control
Type
universal remote control
Remote Control Technology
infrared
Network & Internet Multimedia
Connectivity Interfaces
IEEE 802.3u (Fast Ethernet)
Accessories
Features
LCD display, learning
Audio Specifications
Type
Amplifier
Frequency Response
5 - 100000 Hz
Signal-To-Noise Ratio
103 dB
Power
Form Factor
internal
Battery / Power
Type
power supply
Signal Processing Features
HDMI Switching
Yes
HDMI Pass-Through
up to 1080p
Video Conversion/Scaling
analog to HDMI up conversion
Connections
Type
7.1 channel audio line-in, HDMI input, HDMI output, LAN, S-Video input, S-Video output, SPDIF input, SPDIF output, USB, audio line-in, audio line-out, audio line-out (multi zone), component video input, component video output, composite video output (multi zone), composite video/audio input, composite video/audio output, headphones, monitor output, phono input, remote control, serial, trigger
Qty
2, 3, 4, 6, 8
Connector Type
19 pin HDMI Type A, 4 pin USB Type A, 4 pin mini-DIN, 9 pin D-Sub, RCA, RCA x 2, RCA x 3, RJ-45, TOSLINK, phone stereo 6.3 mm
Connector Location
front, rear
Dimensions & Weight
Depth
18.1 in
Width
16.5 in
Height
7.9 in
